CH SerieLDroove Shape Mixer

specifications

1.CH Series Groove Shape Mixer machinery
2.Model:CH
3.One time mixing:50-300L
4.speed:24r/min

CH Series Groove Shape Mixer

Main Application:

CH Series Groove Shape Mixer is made of stainless steel and applied in pharmaceutical,chemical,foodstuff industry for mixing powder and mash.

Operating Principle:

In the machinery,S-shaped stirring paddle rotates by the mechanical rotational system.It can achieve the accurate mixing.Operator can set time to finish the process automatically on the operating panel to control the quality of mixture.

Technical specification:

Model	volume(L)	Stirring speed(rpm)	Stirring Power(KW)
CH-50	50	24	1.5
CH-100	100	24	2.2
CH-150	150	24	3
CH-200	200	24	4
CH-300	300	24	5.5
Discharge Power(KW)	Overall size(L×W×H)	Weight(kg)
0.5	1200×500×950	320
0.55	1400×580×1000	350
0.75	2000×630×1150	410
1.1	2300×750×1350	450
1.5	2700×850×1500	520

machinery Parts:

Packaging & Shippment:

Certificate:

activity:

Service:

One year guarantee for whole machinery

24 hour technical support by

Calling or door-to-door Service

User manual and detailed video/CD
